СКУ: A9XPH112
A9XPH112 Гребен 1P 100A 12mod
-
Brand
Schneider Electric
-
Number of poles
2
-
Colour
EV000202
-
Insulated
TRUE
-
Cross section
16
-
Number of phases
1
-
Type of electric connection
EV000158
-
Suitable for devices with N-conductor
TRUE
-
Rated permanent current Iu
100
-
Suitable for devices with auxiliary switch
TRUE
-
Module width
18
-
Max. rated operation voltage Ue
415
-
Length
1000
-
Width in number of modular spacings
57
-
Suitable for number of devices
28
This Acti9 product is a cuttable horizontal comb busbar 57 modules for Acti9 iC60 or Acti9 iK60. It is dedicated for N+L1 installations. The type is NL (Neutral, Line). It is a set of 1 device. It is suitable for 28 devices (1P+N). The length is 1000mm. The total number of modules of 18mm is 57. The number of phase is 1. The number of poles is 2. The Ie rated operational current at 40°C is 100A. The Isc short circuit current is compatible with the breaking capacity of Schneider Electric circuit breakers. The Ui rated insulation voltage is 500VAC. The Ue rated operational voltage is 415VAC. The color of the device is white RAL9003. The pollution degree is 3. According to IEC 60695-2-1 standard the fire resistance is self-extinguishing at 960°C within 30s.
