3 PB CONTROL STATION GREEN AVANT

This product is part of Modicon TM3, a range of expansion I/O modules for Modicon plcs. This analogue input module provides 4 inputs with 16bit and 15bit + sign resolution. It is an input module with a 24VDC rated supply voltage, a current consumption of 45mA/50mA at 5VDC via bus connector, 35mA/40mA at 24VDC via external supply. It transfers input signals such as push-buttons, switches, temperature sensors to the plc. It works via a 24VDC external power supply. It is furnished with a removable screw terminal for electrical connection with pitch 3.81mm adjustment for inputs and supply. It measures 23.6mm wide, 70mm deep and 90mm high and it weighs 0.110kg. It is designed to detect the status of input signals such as push-buttons, switches, temperature sensors. This product is certified by CULus, CE, UKCA, RCM, EAC, and cULus HazLoc. This module is compatible with Modicon M262/M241/M251/M221 logic controllers and is configurable with EcoStruxure machine expert software. It is delivered in 1 package (PCE type). It is mounted on a symmetrical DIN rail or with a specific kit for plate or panel mounting. Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. From design and development to commissioning and maintenance, EcoStruxure Machine Expert is a complete machine-building solution.
