10.4 Keypad Panel VGA-TFT

• Brand
  Schneider Electric
• Supporting protocol for SERCOS
  FALSE
• Radio standard GPRS
  FALSE
• Supporting protocol for INTERBUS-Safety
  FALSE
• Supporting protocol for AS-Interface Safety at Work
  FALSE
• Radio standard GSM
  FALSE
• Radio standard UMTS
  FALSE
• Supporting protocol for DeviceNet Safety
  FALSE
• Supporting protocol for Foundation Fieldbus
  FALSE
• Supporting protocol for SafetyBUS p
  FALSE
• Supporting protocol for PROFINET CBA
  FALSE
• Supporting protocol for PROFINET IO
  FALSE
• Supporting protocol for PROFIsafe
  FALSE
• Supporting protocol for ASI
  FALSE
• Radio standard Bluetooth
  FALSE
• Supporting protocol for PROFIBUS
  FALSE
• Radio standard Wi-Fi 802.11
  FALSE
• Supporting protocol for KNX
  FALSE
• Supporting protocol for INTERBUS
  FALSE
• Supporting protocol for DeviceNet
  FALSE
• Suitable for safety functions
  FALSE
• Supporting protocol for Data-Highway
  FALSE
• Supply voltage DC
  24
• Supporting protocol for LON
  FALSE
• Supporting protocol for SUCONET
  FALSE
• Degree of protection (IP), front side
  EV008925
• Rail mounting possible
  TRUE
• Supporting protocol for other bus systems
  FALSE
• Number of HW-interfaces parallel
• Number of interfaces PROFINET
• Number of function buttons, programmable
• Number of HW-interfaces other
• Number of HW-interfaces serial TTY
• With numeric keyboard
  FALSE
• Number of HW-interfaces Wireless
• With alpha numeric keyboard
  FALSE
• Number of buttons with LED
• With message system (incl. buffer and confirmation)
  FALSE
• Process value representation (output) possible
  TRUE
• Supporting protocol for EtherNet/IP
  TRUE
• With SW interfaces
  TRUE
• Number of system buttons
• Supporting protocol for TCP/IP
  TRUE
• Supporting protocol for Modbus
  TRUE
• With message indication
  TRUE
• Number of HW-interfaces USB
  2
• Number of password levels
• With printer output
  FALSE
• Process default value (input) possible
  TRUE
• Additional software components, loadable
  TRUE
• Touch technology
  EV013187
• Screen diagonal
  3.5
• Built-in depth
  74.95
• Voltage type of supply voltage
  EV000509
• Number of pixels, horizontal
  320
• With colour display
  TRUE
• Supporting protocol for CAN
  TRUE
• IO link master
  TRUE
• Width of the front
  128
• Height of the front
  102
• Number of HW-interfaces RS-422
• Wall mounting/direct mounting
  TRUE
• Number of HW-interfaces RS-485
  1
• Number of pixels, vertical
  240
• Number of HW-interfaces industrial Ethernet
  1
• Number of HW-interfaces RS-232
  1
• Number of grey-scales/blue-scales of display
• Degree of protection (NEMA), front side
  EV014040
• With recipes
  FALSE
• Number of online languages
  4
• Operating temperature
  -20
• Useful project memory/user memory
  128
• Type of display
  EV000433
• Number of colours of the display
  65536
