СКУ: 28911
SCHNEIDER ELECTRIC Switch disconnector, Compact INS125, 125A, with black rotary handle, 4P
-
Brand
Schneider Electric
-
Type of electrical connection of main circuit
EV000415
-
Version as emergency stop installation
FALSE
-
Version as reversing switch
FALSE
-
Suitable for front mounting centre
TRUE
-
Rated permanent current Iu
63
-
Voltage release optional
FALSE
-
Device construction
EV009211
-
Version as safety switch
FALSE
-
Rated operating voltage
690
-
Suitable for front mounting 4-hole
TRUE
-
Number of switches
1
-
Motor drive integrated
FALSE
-
Suitable for intermediate mounting
FALSE
-
Motor drive optional
FALSE
-
Rated operation power at AC-23, 400 V
30
-
Version as main switch
TRUE
-
Interlockable
TRUE
-
Version as maintenance-/service switch
TRUE
-
Colour control element
EV000206
-
Suitable for distribution board installation
TRUE
-
Type of control element
EV004095
-
Number of poles
4
-
Conditioned rated short-circuit current Iq
36
-
Max. rated operation voltage Ue AC
500
-
Rated short-time withstand current lcw
3
-
Number of auxiliary contacts as change-over contact
2
-
Degree of protection (IP), front side
EV006415
-
Suitable for floor mounting
TRUE
-
Rated permanent current at AC-23, 400 V
63
-
Number of auxiliary contacts as normally closed contact
-
Number of auxiliary contacts as normally open contact
This Compact INS160 is a 4 poles non-automatic switch-disconnector with red rotary handle and yellow front. It is suitable for isolation with positive contact indication, as defined by IEC 60947-1 and IEC60947-3 standards. The operational current is 160A at 415VAC in categories AC22A and AC23A. The rated voltage is 690VAC 50/60Hz or 250VDC. It can be used as an emergency-off device. For easy identification, it uses special colours stipulated by the standards. The red rotary handle is designed to offer easy operation and high performance in interruption of currents. Compact INS160 is a class II insulation level front-face device as per IEC 60664 standard.
