СКУ: C104MG040
Изключвателно устройство NSX100 AC 4P4D 40A TMG
-
Brand
Schneider Electric
-
Number of poles
4
-
Rated permanent current Iu
100
-
Rated control supply voltage Us at DC
24
-
Type of motor protection
EV014005
-
Voltage type for actuating
EV009206
-
Short-circuit release function
EV003977
-
With ground fault protection function
FALSE
-
Overload release current setting
40
-
End value adjustment range undelayed short-circuit release
1500
-
Initial value of the undelayed short-circuit release - setting range
150
This TM100G is a 4 poles 4d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 100A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.
